UpscalerJS is a tool for increasing image resolution in Javascript via a Neural Network up to 4x.

Demo

A live demo is here.

Announcement​

A beta version of 1.0.0 was released on 7/15/22. Learn more here about what's included.

If you are migrating from <=0.12, and you are using a custom model, you will need to modify how you load models. If you are using the default model (e.g., not providing a model argument) then no changes are needed.

Features

  • πŸ“· Scale images at 2x, 3x, and 4x resolutions.
  • πŸš€ Browser & Node Support
  • πŸ“¦ ️Simple modern ES6 interface
  • πŸ€– Choose from a variety of pre-trained models, or provide your own
  • βš›οΈ Integration with React
  • πŸ›‘οΈ Rigorously tested with close to 100% code coverage

Motivation​

Why?​

Increasing an image's size results in a pixelated image:

Pixelated 2x

Most browsers by default use an algorithm called bicubic interpolation to get a more pleasing version, but this loses image quality and increases blurriness:

Bicubic 2x

Neural Networks can allow us to "paint in" the expanded sections of the image, enhancing quality.

Upscaled 2x

Benefits of the Browser​

Why do this in the browser?

Most cutting edge Neural Networks demand heavy computation and big GPUs, but UpscalerJS leverages Tensorflow.js to run directly in your browser. Users' data can stay on their machines, and you don't need to set up a server.

Getting Started​

Quick Start​

import Upscaler from 'upscaler';
const upscaler = new Upscaler();
upscaler.upscale('/path/to/image').then(upscaledImage => {
console.log(upscaledImage); // base64 representation of image src
});

In Node, make sure you've installed the appropriate Tensorflow.js package, and import the Node-specific Upscaler package.

If using @tensorflow/tfjs-node:

import Upscaler from 'upscaler/node';
const upscaler = new Upscaler();
upscaler.upscale('/path/to/image').then(upscaledImage => {
console.log(upscaledImage); // base64 representation of image src
});

If using @tensorflow/tfjs-node-gpu:

import Upscaler from 'upscaler/node-gpu';
const upscaler = new Upscaler();
upscaler.upscale('/path/to/image').then(upscaledImage => {
console.log(upscaledImage); // base64 representation of image src
});

Install​

Yarn:

yarn add upscaler

NPM:

npm install upscaler

Dependencies​

If running in the browser, UpscalerJS expects @tensorflow/tfjs to be available as a peer dependency.

If running in Node, UpscalerJS expects either @tensorflow/tfjs-node or @tensorflow/tfjs-node-gpu to be available as a peer dependency, depending on whether you import upscaler/node or upscaler/node-gpu.

Examples​

You can view runnable code examples on CodeSandbox.

Usage​

Instantiation​

By default, when UpscalerJS is instantiated, it uses the default model, @upscalerjs/esrgan-slim.

You can install alternative models by installing them and providing them as an argument. For instance, to use @upscalerjs/esrgan-legacy, you'd first install it:

npm install @upscalerjs/esrgan-legacy

And then import and provide it:

import Upscaler from 'upscaler';
import GANS from '@upscalerjs/esrgan-legacy/gans';
const upscaler = new Upscaler({
model: GANS,
});

Currently, the list of models includes:

  • @upscalerjs/esrgan-slim
  • @upscalerjs/esrgan-legacy

Alternatively, you can provide a path to a pre-trained model of your own:

const upscaler = new Upscaler({
model: {
path: '/path/to/model',
scale: 2,
},
});

When providing your own model, you must provide an explicit scale.

The full model definition is defined here.

Upscaling​

You can upscale an image with the following code:

upscaler.upscale('/path/to/image').then(img => {
console.log(img);
});

In the browser, you can provide the image in any of the following formats:

  • string - A URL to an image. Ensure the image can be loaded (for example, make sure the site's CORS policy allows for loading).
  • tf.Tensor3D or tf.Tensor4D - A tensor representing an image.
  • Any valid input to tf.browser.fromPixels

In Node, you can provide the image in any of the following formats:

  • string - A path to a local image, or if provided a string that begins with http, a URL to a remote image.
  • tf.Tensor3D or tf.Tensor4D - A tensor representing an image.
  • Uint8Array - a Uint8Array representing an image.
  • Buffer - a Buffer representing an image.

By default, a base64-encoded src attribute is returned. You can change the output type like so:

upscaler.upscale('/path/to/image', {
output: 'tensor',
}).then(img => {
console.log(img);
});

The available types for output are:

  • src - A src URL of the upscaled image.
  • tf.Tensor3D - The raw tensor.

Performance​

For larger images, attempting to run inference can impact UI performance. To address this, you can provide a patchSize parameter to infer the image in "patches" and avoid blocking the UI. You will likely also want to provide a padding parameter:

({
patchSize: 64,
padding: 5,
})

Without padding, images will usually end up with unsightly artifacting at the seams between patches. You should use as small a padding value as you can get away with (usually anything above 3 will avoid artifacting).

Smaller patch sizes will block the UI less, but also increase overall inference time for a given image.

API​

constructor​

Instantiates an instance of UpscalerJS.

Example​

const upscaler = new Upscaler({
scale: 2,
warmupSizes: [[256, 256]]
});

Options​

  • model (ModelDefinition) - A configuration of a pretrained model.
  • scale (number) - The scale of the custom pretrained model. Required if providing a custom model. If a pretrained model is specified, providing scale will throw an error.
  • warmupSizes (Optional, Array<[number, number] | { patchSize: number, padding?: number }>) - An array of sizes to "warm up" the model. By default, the first inference run will be slower than the rest. This passes a dummy tensor through the model to warm it up. It must match your image size exactly. Sizes are specified as [width, height].

upscale​

Accepts an image and returns a promise resolving to the upscaled version of the image.

Example​

upscaler.upscale('/path/to/image', {
output: 'tensor',
patchSize: 64,
padding: 5,
progress: (amount) => {
console.log(`Progress: ${amount}%`);
}
}).then(upscaledImage => {
...
});

Options​

  • src (str|HTMLImage|tf.Tensor3D) - Path to the image, or an HTMLImage representation of the image, or a 3-dimensional tensor representation of the image.
  • options
    • output (src|tensor) - The desired output of the function. Defaults to a base 64 src representation.
    • patchSize (number) - The desired patch size to use for inference.
    • padding (number) - Extra padding to be applied to the patch size during inference.
    • progress ((amount: number, slice?: src|tensor) => void) - A progress callback denoting the percentage complete.
    • progressOutput (src|tensor) - An optional value that sets the return type of the second argument of progress
    • signal (AbortSignal) - An optional signal that allows cancellation of an in-flight upscale request

The progress callback optionally returns a second argument with the processed slice of the image:

upscaler.upscale('/path/to/image', {
output: 'tensor',
progress: (amount, slice) => {
// do something with the sliced image
}
});

The slice format will be a base64 string or a tensor corresponding to the value of output. This can be overridden by providing an additional property, progressOutput, of the form src | tensor that will override the value set in output.

You can cancel an upscale request by providing an AbortSignal:

const abortController = new AbortController();
upscaler.upscale('/path/to/image', {
signal: abortController.signal,
}).catch(err => {
// I have been cancelled.
});
abortController.abort();

It's worth noting that calls to model.predict() in Tensorflow.js cannot be aborted; if you wish to enable the ability to cancel an inflight request, specifying patch sizes will periodically allow the upscale request to release and potentially abort.

warmup​

If desired, the model can be "warmed up" after instantiation by calling warmup directly.

Example​

upscaler.warmup([[256, 256]]).then(() => {
// all done.
});

Or you can provide a patch size and padding:

upscaler.warmup([{
patchSize: 64,
padding: 5,
}]).then(() => {
// all done.
});

Options​

  • warmupSizes (Optional, Array<[number, number]>) - An array of sizes to "warm up" the model.

getModel​

Gets the underlying model.

Example​

upscaler.getModel().then(model => {
})

dispose​

Disposes the current model. Must be called to free up memory when the Upscaler is no longer needed.

Example​

await upscaler.dispose();

abort​

Aborts all inflight upscale calls.

Example​

await upscaler.abort();

Troubleshooting​

Padding is undefined​

If specifying a patch size but not padding, you will likely encounter artifacting in the upscaled image.

Image with artifacting

Most of the time, this artifacting is undesired. To resolve the artifacting, add an explicit padding:

upscaler.upscale('/path/to/img', {
patchSize: 64,
padding: 4,
})

Image with artifacting

If you would like to keep artifacting but hide the warning message, pass an explicit padding value of 0:

upscaler.upscale('/path/to/img', {
patchSize: 64,
padding: 0,
})

Progress Specified Without Patch Size​

If you've specified a progress callback but are not specifying patchSize in the call to upscale, the progress callback will never be called. progress callbacks only occur when patchSize is provided.

In order to have your progress callback be called, provide explicit patch sizes:

upscaler.upscale('/path/to/img', {
patchSize: 64,
progress: ...
})

Contributions​

Contributions are welcome! Please follow the existing conventions, use the linter, add relevant tests, and add relevant documentation.

Support​

License​

This project is licensed under the MIT License. See the LICENSE for details.

Copyright (c) Kevin Scott (@thekevinscott)
